• Powered lift/lower & powered extend/retract jib arm
  • Manual push/pull
  • Electro hydraulic powered Lift/Lower/extend & retract
  • Battery power 12v 110 Ah
  • 4 way fine control lever controls the Lift/lower/extending & retracting jib arm
  • Fixed jib arm
  • Max SWL 1000kg
  • Jib extension manual
  • Maximum standard extension 1250mm
  • Maximum with optional extended jib arm 2000mm
  • Max lift height 3119mm
  • O/A dimensions with jib arm down L2100 x W955 x H1780mm
  • Machine weight 1208kg
  • Fixed front wheels
  • Rear rotating castors with brake
  • CE marked (Complete with SWL test certificate)
  • EN standards compliant

Enquire About This Equipment

This field is for validation purposes and should be left unchanged.

Integrating a powered lift/lower and powered extend/retract jib arm with a range of advanced features. This counterbalanced crane is complemented by a manual push/pull mechanism, it ensures precise load handling. Driven by a 12v 110 Ah battery, the electro-hydraulic system empowers seamless and controlled lift/lower and extension/retraction actions. The four-way fine control lever offers a comprehensive command over the lift, lower, extending, and retracting jib arm movements, elevating operational precision.

The equipment’s fixed jib arm, combined with its robust maximum safe working load (SWL) of 1000kg, positions it as an invaluable choice for heavy-duty lifting needs. Its manual jib extension feature enhances its adaptability, offering a standard extension of 1250mm and an optional extended jib arm reaching an impressive 2000mm. The equipment attains a maximum lift height of 3119mm, facilitating easy access to elevated areas.

When the jib arm is lowered, the equipment’s overall dimensions measure L2100 x W955 x H1780mm. Its substantial machine weight of 1208kg ensures stability during operation. The addition of fixed front wheels enhances control, while rear rotating castors equipped with a dependable brake system provide precise mobility control, even in demanding conditions. Bearing the CE mark and accompanied by a comprehensive safe working load (SWL) test certificate, the equipment underscores its dedication to adhering to safety standards. Full compliance with EN standards solidifies its status as a reliable and adaptable tool, well-suited to excel across a multitude of industries, delivering efficiency and accuracy in every task.
