• Powered lift/lower jib arm
  • Manual push/pull
  • Lift/Lower powered by 12v 110 Ah, powering electro-hydraulic
  • Lift/lower controlled by pendant push button with emergency stop
  • Unique 270 degree free rotating Jib arm with 5 locking positions
  • Max SWL 200kg
  • Jib extension manual
  • Maximum standard extension 860mm
  • Maximum with optional extended jib arm 1360mm
  • Max lift height 2804mm
  • O/A dimensions with jib arm down L1342 x W955 x H1780mm
  • Machine weight 440kg
  • Fixed front wheels
  • Rear rotating castors with brake
  • CE marked (Complete with SWL test certificate)
  • EN standards compliant

Enquire About This Equipment

This field is for validation purposes and should be left unchanged.

The equipment represents a pinnacle of efficiency and versatility in lifting operations, bolstered by its remarkable features. Offering a powered lift/lower jib arm, it ensures seamless load positioning. Powered by a 12v 110 Ah source, the electro-hydraulic system drives the lift/lower mechanism, affording both convenience and precision. Counterbalanced crane is controlled by a pendant push button equipped with an emergency stop, ensuring safety remains paramount.

An outstanding feature is the unique 270-degree free-rotating jib arm, complete with five locking positions for optimal flexibility. With a maximum safe working load (SWL) of 200kg, it is equipped to handle a diverse range of loads. The manual jib extension adds further adaptability, with a standard extension of 860mm and the option for an extended jib arm reaching an impressive 1360mm. Achieving a maximum lift height of 2804mm, it facilitates access to elevated areas with ease.

The equipment’s overall dimensions, with the jib arm lowered, measure L1342 x W955 x H1780mm, and it boasts a sturdy machine weight of 440kg. Fixed front wheels enhance stability, while rear rotating castors, complete with a brake system, ensure controlled movement during operation. Holding the prestigious CE mark and accompanied by an SWL test certificate, it meets stringent safety standards. This equipment aligns seamlessly with EN standards compliance, making it a reliable and efficient asset across various industries.

The lifter Lift Safe supplied is excellent, both operators of the laying machine have said its works perfectly and saves a lot of heavy lifting sometimes with 2 people, as you will see from the photos the roll needs to be lifted to almost head height so previously it was a struggle, however with your lifter the job is much easier and safer now.

Mike Greer. Manager. AMR Textiles
