01M2
This hydraulic counterbalanced crane showcases an impressive array of features that cater to efficient and controlled lifting operations. With a manual hydraulic lift lower jib arm, it provides precise control over load placement. The manual push/pull mechanism ensures smooth movement, while the hydraulic lever-controlled fast lift double-action pump empowers swift lifting actions. For meticulous descent control, a fine control descent knob is integrated. The equipment's standout feature is its unique free-rotating jib arm, offering five locking positions for enhanced manoeuvrability. Boasting a maximum safe working load (SWL) of 200kg, it excels in managing various loads.
This equipment is designed to cater to a wide range of lifting needs, delivering efficiency and safety in line with EN standards compliance. Its comprehensive features and thoughtful design make it an invaluable asset across various industries.
- Traction – Manual
- Max Capacity (Kg) – 200
- Column – Swivel 360°
- Max Overhang (mm) – 1270
- Max Height (mm) – 2850
- Frontal footprint (mm) – 800
- Lifting – Fast lift double action pump
- Lowering – Fine control descent knob
- Boom – Manual 4 positions
| Max. lifting capacity | 200kg |
|---|---|
| Max. lifting height | 2850 |
| Column | Swivel 360° |
| Max. overhang | 1270 |
