• Powered lift/lower & powered extend/retract jib arm
  • Manual push/pull
  • Electro hydraulic powered Lift/Lower/extend & retract
  • Battery power 12v 110 Ah
  • 4 way fine control lever controls the Lift/lower/extending & retracting jib arm
  • 360 degree free rotating Jib arm with 8 locking positions
  • Max SWL 500kg
  • Jib extension manual
  • Maximum standard extension 1410mm
  • Maximum with optional extended jib arm 1360mm
  • Max lift height 2258mm
  • O/A dimensions with jib arm down L1310 x W990 x H1932mm
  • Machine weight 680kg
  • Fixed front wheels
  • Rear rotating castors with brake
  • CE marked (Complete with SWL test certificate)
  • EN standards compliant

Enquire About This Equipment

This field is for validation purposes and should be left unchanged.

The equipment sets a new standard in lifting versatility, combining powerful features for precision operations. A counterbalanced crane powered lift/lower and powered extend/retract jib arm functions redefine load positioning and reach extension. The electro-hydraulic system, powered by a 12v 110 Ah battery, ensures seamless and controlled lift/lower and extension/retraction actions. The four-way fine control lever offers a comprehensive command over the lift, lower, extending, and retracting jib arm movements, enhancing operational precision.

The 360-degree free-rotating jib arm with eight locking positions is a standout feature that guarantees optimal maneuverability in all directions. With a remarkable maximum safe working load (SWL) of 500kg, the equipment is engineered for robust performance. Its manual jib extension provides additional flexibility, featuring a standard extension of 1410mm and the option for an extended jib arm reaching 1360mm. This equipment achieves a maximum lift height of 2258mm, ensuring access to elevated areas with ease and accuracy.

When the jib arm is lowered, the equipment’s overall dimensions measure L1310 x W990 x H1932mm. Its substantial machine weight of 680kg ensures stability during operation. Fixed front wheels enhance controlled movement, while rear rotating castors equipped with a brake system ensure precise mobility even in challenging environments. Bearing the CE mark and accompanied by an SWL test certificate, the equipment’s adherence to stringent safety standards is evident. Complete compliance with EN standards solidifies its reputation as a reliable and adaptable tool, making it an indispensable asset across various industries.
